*ESR? (standard Event Status
Register)
Function Queries and clears the standard event register.
Syntax
*ESR?
Example
*ESR?
-> 32
Description A sum of the values of each bit is returned in
decimal format.
When an SRQ is generated, you can check
what types of events have occurred.
For example, if a value of 32 is returned, this
indicates that the standard event register is
set to 00100000. This means that the SRQ
occurred due to a command syntax error.
A query using
*ESR?
will clear the contents of
the standard event register.
For information about the standard event
register, see page 6-3.
*IDN? (IDeNtify)
Function Queries the DLM2000 model.
Syntax
*IDN?
Example
*IDN?
-> YOKOGAWA,710120,08ELP1024,F1.01
Description The information is returned in this
form:<Manufacturer>, <Model>, <Serial no.>,
<Firmware version>.
The following values are returned for <Model>:
710105 for the DLM2022, 710110 for the
DLM2024, 710115 for the DLM2032, 710120 for
the DLM2034, 710125 for the DLM2052, and
710130 for the DLM2054.
*OPC (OPeration Complete)
Function Sets bit 0 (the OPC bit) of the standard event
register to 1 upon the completion of the specified
overlap command.
Syntax
*OPC
Example
*OPC
Description For information about how to synchronize a
program using
*OPC
, see page 5-7.
• The
:COMMunicate:OPSE
command is used
to specify the overlap command.
• If
*OPC
is not the last command of the message,
its operation is not guaranteed.
5.38 Common Command Group
The commands in this group are defined in USBTMC-USB488 and are independent from the instrument’s individual
functions. There are no front panel keys that correspond to the commands in this group.
*CAL? (CALibrate)
Function Executed calibration and queries the result.
Syntax
*CAL?
Example
*CAL?
-> 0
Description If the calibration terminates normally, 0 is returned.
If an error is detected, 1 is returned.
*CLS (CLear Status)
Function Clears the standard event register, extended event
register, and error queue.
Syntax
*CLS
Example
*CLS
Description • If the
*CLS
command is located immediately
after the program message terminator, the
output queue is also cleared.
For information about each register and queue,
see chapter 6.
*ESE (standard Event Status Enable
register)
Function Sets or queries the standard event enable register.
Syntax
*ESE {<NRf>}
*ESE?
<NRf> = 0 to 255
Example
*ESE 251
*ESE?
-> 251
Description Specify the value as a decimal format sum of
the values of each bit.
For example, specifying
*ESE 251
will cause
the standard enable register to be set to
11111011. In this case, bit 2 of the standard
event register is disabled. This means that bit 5
(ESB) of the status byte register is not set to 1,
even if a query error occurs.
The default value is
*ESE 0
(all bits disabled).
A query using
*ESE?
will not clear the contents
of the standard event enable register.
For information about the standard event enable
register, see page 6-3.
