YOKOGAWA DLM2000 Series User Manual

5-232
IM 710105-17E
5.33 TRIGger Group
The following table indicates how the communication commands for trigger types correspond to the menu items that
appear on the screen.
Trigger Type Communication
Command
Setup Menu
Trigger Menu Trigger Type
Edge trigger SIMPle EDGE —
Trigger on the OR of multiple edge triggers OR ENHANCED Edge OR
Edge qualified trigger QUALify Edge Qualify
State trigger PATTern State
pulse width trigger PULSe Pulse Width
State width trigger WIDTh State Width
Serial trigger (CAN, CAN FD, LIN, SENT,
PSI5 Airbag, UART, I2C, SPI, FlexRay, and
User Define)
CAN* CAN
CANFD* CAN FD
LIN* LIN
SENT* SENT
PSI5* PSI5 Airbag
UART* UART
I2C* I2C
SPI* SPI
FLEXray* FlexRay
SPATtern User Define
TV trigger (NTSC, PAL, SDTV, HDTV, and User
Define)
TV:NTSC NTSC
TV:PAL PAL
TV:SDTV SDTV
TV:HDTV HDTV
TV:USERdefine User Define
* CAN, CANFD, LIN, SENT, PSI5, UART, I2C, SPI, and FLEXray are serial bus options available only for
4-channel models. Communication commands for these serial buses cannot be used on 2-channel models or
4-channel models without serial bus options.
:TRIGger?
Function Queries all trigger settings.
Syntax
:TRIGger?
:TRIGger:ABN?
Function Queries all A->B(n) trigger settings.
Syntax
:TRIGger:ABN?
:TRIGger:ABN:COUNt
Function Sets or queries the number of times condition B
must be met for the A->B(n) trigger.
Syntax
:TRIGger:ABN:COUNt {<NRf>}
:TRIGger:ABN:COUNt?
<NRf> = 1 to 1000000000
Example
:TRIGGER:ABN:COUNT 1
:TRIGGER:ABN:COUNT?
-> :TRIGGER:ABN:COUNT 1
:TRIGger:ACTion?
Function Queries all action-on-trigger settings.
Syntax
:TRIGger:ACTion?
:TRIGger:ACTion:ACQCount
Function Sets or queries the action-on-trigger action.
Syntax
:TRIGger:ACTion:ACQCount {<NRf>|
INFinite}
:TRIGger:ACTion:ACQCount?
<NRf> = 1 to 1000000
Example
:TRIGGER:ACTION:ACQCOUNT 1
:TRIGGER:ACTION:ACQCOUNT?
-> :TRIGGER:ACTION:ACQCOUNT 1
:TRIGger:ACTion:BUZZer
Function Sets or queries the whether or not the DLM2000
will sound an alarm as an action when trigger
conditions are met (on/off).
Syntax
:TRIGger:ACTion:BUZZer {<Boolean>}
:TRIGger:ACTion:BUZZer?
Example
:TRIGGER:ACTION:BUZZER ON
:TRIGGER:ACTION:BUZZER?
-> :TRIGGER:ACTION:BUZZER 1
