5-14
IM DLM5058-03EN
4.
Press the Enter soft key. The additional option will be installed. When the option is installed
successfully, the following screen appears.
Additional option indication
The installed additional option is
displayed.
Restarting
5.
Restart the instrument. The additional option will be activated.
Viewing the System Information
6.
To verify that the option has been installed, view the system information on the instrument
overview screen. For instructions on how to display the overview screen, see section 5.4.
Note
The SUFFIX (suffix code) inscribed in the name plate on the instrument’s case indicates the installed
options at the time of factory shipment. After you add options through additional option licenses, check the
options on the instrument overview screen.
5.5 Adding Options to the Instrument
To Next Page
