6-20
IM DLM5058-03EN
6.10 Computer Interface
GP-IB (option)
Item Specifications
Electrical and mechanical Complies with IEEE St’d 488-1978 (JIS C 1901-1987)
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, C0
Protocol Complies with IEEE St’d 488.2-1992
Code ISO (ASCII) codes
Mode Addressable mode
Address Talker and listener addresses can be specified from 0 to 30.
Clear remote mode Remote mode can be cleared with the SHIFT+CLEAR TRACE key (except during Local Lockout).
USB for PC Connection
Item Specifications
Connector type USB type B (receptacle)
Electrical and mechanical USB Rev. 3.0 compliant
Supported transfer modes FS (Full Speed) mode (12 Mbps), HS (High Speed) mode (480 Mbps), SS (Super Speed) mode (5
Gbps)
Number of ports 1
Supported protocols Functions as a device that conforms to one of the following two protocols.
USBTMC-USB488 (USB Test and Measurement Class Ver. 1.0)
*
Communication commands can be used through USB.
Mass Storage Class Ver. 1.1
Only reading is possible from the instrument’s internal storage through PC access.
(Operations, such as formatting, are not possible.)
PC system requirements A PC with a USB port, running the English or Japanese version of Windows 8.1 (32 bit or 64 bit) or
Windows 10 (32 bit or 64 bit)
* A separate driver is required.
Ethernet
Item Specifications
Connector type RJ-45 connector
Ports 1
Electrical and mechanical
specifications
IEEE 802.3 compliant
Transmission system Ethernet (1000BASE-T, 100BASE-TX, 10BASE-T)
Communication protocol TCP/IP
Supported services Server: FTP, VXI-11, Socket
Client: FTP (Net Drive), SMTP (Mail), SNTP, LPR (Net Print), DHCP, DNS, PTP
PC system requirements A PC running the English or Japanese version of Windows 8.1 (32 bit or 64 bit) or Windows 10 (32
bit or 64 bit)
