App-14
IM DLM5058-03EN
Appendix 2 USB Keyboard Key Assignments
Panel Operation on the Instrument USB keyboard
ACQUIRE CTRL+A
MATH/REF CTRL+B
Executing an PRINT CTRL+C
DISPLAY CTRL+D
ENHANCED CTRL+E
FILE CTRL+F
ACTION, GO/NO-GO CTRL+G
HISTORY CTRL+H
Resetting to factory default settings CTRL+I
Execute auto setup CTRL+J
ANALYSIS CTRL+K
LOGIC CTRL+L
MEASURE CTRL+M
CURSOR CTRL+N
SEARCH CTRL+O
Set the trigger level to 50% CTRL+P
Execute CLEAR TRACE CTRL+Q
Execute RESET CTRL+R
SHIFT on CTRL+S
TRIGGER MODE CTRL+T
UTILITY CTRL+U
Set the vertical position to 0 div CTRL+V
EDGE CTRL+W
ZOOM2 CTRL+X
B TRIG CTRL+Y
ZOOM1 CTRL+Z
CH1 CTRL+1
CH2 CTRL2
CH3 CTRL3
CH4 CTRL4
CH5 CTRL5
CH6 CTRL6
CH7 CTRL7
CH8 CTRL8
Executing an HELP CTRL+/
Turn the touch panel feature on and off CTRL+[
Executing an SET CTRL+ENTER
Executing an ESC Esc
FFT CTRL+SHIFT+B
PRINT MENU CTRL+SHIFT+C
X-Y CTRL+SHIFT+D
SERIAL BUS CTRL+SHIFT+O
Set the horizontal position to 50% CTRL+SHIFT+P
CH UTIL CTRL+SHIFT+U
Switch the SCALE knob between FINE mode and 1-2-5 step mode CTRL+SHIFT+V
Execute FORCE TRIG CTRL+SHIFT+Y
Switch the ZOOM knob between FINE mode and 1-2-5 step mode CTRL+SHIFT+X
Select soft key 1 F1
Select soft key 2 F2
Select soft key 3 F3
Select soft key 4 F4
Select soft key 5 F5
