6-18
IM DLM5058-03EN
6.9 Auxiliary I/O Section
External Trigger Input (TRIGGER IN)
Item Specifications
Connector type BNC
Input bandwidth* DC to 100 MHz
Input impedance Approx. 1 MΩ, approx. 16 pF
Maximum input voltage ±40 V (DC + AC peak) or 28 Vrms
(At 1 MHz and higher, the voltage decreases at 20 dB/decade down to ±5 V (DC+ACpeak) or 2
Vrms.)
Input range ±2 V
±20 V
Trigger level ±2 V. The resolution is 5 mV (for the ±2 V range).
±20 V. The resolution is 50 mV (for the ±20 V range).
* Under standard operating conditions (see section 6.12) after warm-up
Trigger Output (TRIGGER OUT)
Item Specifications
Connector type BNC
Output level 3.3 V CMOS
Output impedance Approx. 50 Ω
Output logic
(negative logic) and (positive logic) switchable
Output delay time 600 ns or less*
Output hold time Negative logic: Low level: 500 ns min. High level: 50 ns min.
Positive logic: High level: 500 ns min. Low level: 50 ns min.
* When deskewing is not used
Video Signal Output (VIDEO OUT)
Item Specifications
Connector type D-sub 15 pin (receptacle)
Output type Analog RGB output
Output resolution XGA-compliant output, 1024 × 768 dots, approx. 60-Hz Vsync (66.7 MHz dot clock frequency)
GO/NO-GO Determination Output
Item Specifications
Connector type RJ-12 modular jack
Signal GO OUT, NO-GO OUT
Output level TTL compatible
Compliant cable Four-wire modular cable
To Next Page
