Chapter 6 Specifications
6.1 Signal Input Section
Analog Signal Input
Item Specifications
Number of input channels DLM5034, DLM5054: 4 (CH1 to CH4)
DLM5038, DLM5058: 8 (CH1 to CH8)
Input coupling settings AC1MΩ, DC1MΩ, DC50Ω
Input connector BNC connector
Input impedance 1 MΩ ± 1.0%, approx. 16 pF
50 Ω ±1.0% (VSWR1.4 or less at DC to 500 MHz)
Voltage scale setting 1 MΩ input: 500 μV/div to 10 V/div (1-2-5 steps)
50 Ω input: 500 μV/div to 1 V/div (1-2-5 steps)
Maximum input voltage 1 MΩ input: 300 Vrms and 400 Vpeak; neither values may be
exceeded. (At 100 kHz and higher, the voltage
decreases at 20 dB/decade down to 2 Vrms.)
50 Ω input: 5 Vrms and 10 Vpeak; neither values may be
exceeded.
Selectable maximum DC offset
range
(when the probe attenuation is
set to 1:1)
1 MΩ input
500 µV/div to 50 mV/div: ±1 V
100 mV/div to 500 mV/div: ±10 V
1 V/div to 10 V/div: ±100 V
50 Ω input
500 µV/div to 50 mV/div: ±1 V
100 mV/div to 1 V/div: ±5 V
Vertical (voltage) axis accuracy
DC accuracy
1
500 µV/div: ±(3.0% of 8 div + offset voltage accuracy)
1 mV/div to 10 V/div: ±(1.5% of 8 div + offset voltage accuracy)
Offset voltage accuracy
1
500 µV/div to 50 mV/div: ±(1% of setting +0.2 mV)
100 mV/div to 500 mV/div: ±(1% of setting +2 mV)
1 V/div to 10 V/div: ±(1% of setting +20 mV)
Frequency bandwidth
(≥‒3 dB)
*1*2
(± 3 divp-p sine wave input)
1 MΩ input (measured from the probe tip when using the supplied 10:1 passive probe (10:1
conversion))
DLM5034, DLM5038 DLM5054, DLM5058
20 mV/div to 100 V/div: DC to 350 MHz DC to 500 MHz
10 mV/div: DC to 350 MHz DC to 350 MHz
5 mV/div: DC to 200 MHz DC to 200 MHz
50 Ω input
DLM5034, DLM5038 DLM5054, DLM5058
2 mV/div to 1 V/div: DC to 350 MHz DC to 500 MHz
1 mV/div: DC to 350 MHz DC to 350 MHz
500 µV/div: DC to 200 MHz DC to 200 MHz
–3 dB point for AC coupling Approx. 1 Hz (for direct input)
1 Hz or less (when using the supplied 10:1 probe)
Skew between channels
(when channels are set to the
same conditions)
100 ps or less (typical value
4
)
Residual noise level
3
0.2 mVrms or 0.05 div rms, whichever is greater (typical value
4
)
Isolation between channels
(when set to the same voltage
scale)
Maximum bandwidth: ‒34 dB (typical value
4
)
1 Values measured under standard operating conditions as indicated in section 6.12 after a 30-minute warm-up and calibration.
2 Values for repeating phenomena. The single-shot frequency bandwidth is from DC to the sampling frequency/2.5 or is the
frequency bandwidth of the repeating phenomena, whichever is less.
3 Values when the input section is shorted, the acquisition mode is set to Normal, accumulation is set to off, and the probe
attenuation is set to 1:1.
4 Typical values represent typical or average values. They are not strictly warranted.
