6-2
IM DLM5058-03EN
Item Specifications
A/D converter resolution 8 bit (25LSB/div)
12 bits maximum (during high-resolution mode)
Probe attenuation settings Voltage probe: 0.001:1 to 2000:1 (1-2-5 steps)
Current probe: 0.001A:1V to 2000A:1V (1-2-5 steps)
Bandwidth Limit For each channel, you can select FULL, 200MHz, 100MHz, 20MHz, 10MHz, 5MHz, 2MHz,
1MHz, 500kHz, 250kHz, 125kHz, 62.5kHz, 32kHz, 16kHz, or 8kHz.
Uses IIR and FIR digital filters
Maximum sample rate Real-time sampling mode: 2.5 GS/s (1.25 GS/s). Values inside parentheses are
for high resolution mode.
Repetitive sampling mode: 250 GS/s
*
Interpolation sampling mode: 250 GS/s
Maximum record length Maximum record length for which repetitive acquisitions are possible
No options: 12.5 MPoints
On models with the /M1S or /M1 option: 25 MPoints
On models with the /M2S or /M2 option: 50 MPoints
Maximum record length for which a single acquisition is possible
(
Values inside parentheses
can be used only for odd channels.)
No options: 50 MPoints (125 MPoints)
On models with the /M1S or /M1 option: 125 MPoints (250 MPoints)
On models with the /M2S or /M2 option: 250 MPoints (500 MPoints)
* Repetitive sampling mode is not possible when the trigger source is set to logic input.
6.1 Signal Input Section
