Specifications
6
6.11 Synchronous Operation (DLMsync, Optional)
Item Specifications
Connection method Using a connection cable (701982-01, 701982-02), connect two of the following instruments:
DLM5034, DLM5054, DLM5038, DLM5058.
Synchronized items Measurement start/stop, sampling clock, clock (time), trigger
Inter-unit sampling skew When the connection cable (701982-01) is used: 20.20 ns (typical value
*
)
When the connection cable (701982-02) is used: 27.90 ns (typical value
*
)
Adjustable within ±50 ps using the deskew feature
Inter-unit skew adjustment
(Deskew) feature
Adjusts the inter-unit sampling skew
Adjustment range: 15.0 ns to 35.0 ns (0.05 ns resolution)
* Typical values represent typical or average values. They are not strictly warranted.
