6-19
IM DLM5058-03EN
Specifications
6
Front Panel Probe Interface Terminal
Item Specifications
Output terminals DLM5034, DLM5054: 4
DLM5038, DLM5058: 8
Output voltage ±12 V ± 5% (up to 2.0 A in combination with the side panel probe power terminal), ±5 V ± 5% (up to
1.6 A total)
Usable probes Differential probes (701924, 701925, 701927), current probes (701928, 701929)
Side Panel Probe Power Terminal (option)
Item Specifications
Output terminals DLM5034, DLM5054: 4
DLM5038, DLM5058: 8
Output voltage ±12 V (up to 2.0 A in combination with the front panel probe power terminal)
Usable probes FET probe (700939), current probe (701917, 701918, 701930, 701931, 701932, 701933, 702915,
702916), differential probes (700924, 700925, 701920, 701921, 701922, 701926, 701977, 701978)
Synchronous Operation I/O (SYNC)
Item Specifications
Connector type 26-pin half pitch (female)
Compliant cable Connection cable (701982-01, 701982-02)
6.9 Auxiliary I/O Section
To Next Page
