2-24
IM DLM5058-03EN
Loading the Roll Paper
CAUTION
• Do not touch the print head. If you do, you may burn yourself.
• Do not touch the roll paper cutter section at the end of the printer cover. Doing so may
cause injury.
French
ATTENTION
• Ne pas toucher la tête d’impression. Vous pourriez vous brûler.
• Ne pas toucher la section du coupe-papier à l’extrémité du cache de l’imprimante. Vous
pourriez vous blesser
Raise the handle.
Printer cover
OPEN COVER
Button
Roll paper cutter section
Print head
Align the ends of the roll paper
with the guides and set the roll
in place.
Close the printer cover and press
LOCK at the center of the cover
until you hear a click.
Press OPEN COVER to open the
printer cover.
Guide
Set the roll paper
in the orientation
shown in the figure.
5.
2.8 Loading Roll Paper Into the Built-In Printer (Optional)
To Next Page
