1 Make sure that the attached power cord meets the designated standards of the country and area that you
are using it in. If the suffix code is -Y, a power cord is not included.
2 Included only on models with the optional built-in printer (/B5)
3 On models with the /E1 option, four 701937 passive probes are provided in addition to the four standard
701937 passive probes. On models with the /E2 option, four 701949 miniature passive probes are
provided instead of the four standard 701937 passive probes. On models with the /E3 option, eight
701949 miniature passive probes are provided instead of the four standard 701937 passive probes.
4 The soft case can be affixed to the front panel protection cover. Hook-and-loop fasteners are attached to
the back side of the soft case.
Soft case
Front panel protection cover
Hook-and-loop fasteners
Where to affix the hook-and-loop fasteners
Manual CD
The English folder in the manual CD contains the PDF files shown below. The CD also
contains Japanese manuals.
File Name Manual Title Manual No.
Features Guide & Users Manual.pdf DLM5034, DLM5038, DLM5054, DLM5058
Mixed Signal Oscilloscope
Features Guide
IM DLM5058-01EN
DLM5034, DLM5038, DLM5054, DLM5058
Mixed Signal Oscilloscope
User’s Manual
IM DLM5058-02EN
Communication Interface.pdf DLM5034, DLM5038, DLM5054, DLM5058
Mixed Signal Oscilloscope
Communication Interface User’s Manual
IM DLM5058-17EN
To view the PDF data, you need Adobe Acrobat Reader or a software application that can
open PDF data.
Checking the Contents of the Package
