3-24
IM DLM5058-03EN
Note
• The auto setup feature may not work properly for signals that include a DC component or high-frequency
components.
• To measure serial bus signals, execute auto setup from the appropriate serial bus signal setup menu.
Settings after the Execution of Auto Setup
CH1 to CH8 Settings
Position 0 div
Coupling The same as the value used before you executed auto setup.
However, if the setting before executing the auto setup was AC,
this is set to DC.
Bandwidth Full
Offset 0 V
Invert OFF
Acquisition Settings
Record Length The same as the value used before you executed auto setup.
However, if the record length is such that the instrument can
only acquire waveforms in Single mode, the record length is
set to the maximum record length at which the instrument can
acquire waveforms repeatedly.
Mode Normal
Hi Resolution OFF
Sampling Mode Interpolation
Trigger Settings
Trigger Type Edge
Trigger Mode Auto
Holdoff 20 ns
Delay 0 s
Position 50%
Slope
Rising (
)
HF Rejection OFF
Noise Rejection
Low (
)
Settings That Depend on the Input Signal
Display On if the instrument detects a voltage of ±20 mV (1:1) or higher
and off otherwise
V/div The instrument selects the range with the highest sensitivity that
does not exceed ±3.5 div.
Trigger Level Center
Trigger Source The channel with the lowest frequency among the signals
whose amplitude (Max – Min) is at least 1 div
Time/div The fastest sweep range that allows at least two periods of the
fastest signal among the signals whose amplitude is at least 1
div to be observed. The sweep range must be at least 5 ms/div.
The values of settings not listed here do not change.
3.6 Performing Auto Setup
To Next Page
