3.2.2 Menu Tree
A: DISPLAY
HOME
A10: OUTPUT
A11: PRES
A15: OUTPUT mA
A16: ENGR. OUTPUT
A17: ENGR. EXP
A20: SP %
*
1
A21: SP
*
1
A30: CAPSULE TEMP
A60: SELF CHECK
B10: MODEL
B11: STYLE NO.
B20: PRES LRL
B21: PRES URL
B22: P MIN SPAN
B30: SP LRL
*
1
B31: SP URL
*
1
B32: SP MIN SPAN
*
1
B60: SELF CHECK
C: BASIC SETUP
C10: TAG NO.
C20: PRES UNIT
C21: PRES LRV
C22: PRES URV
C23: PRES POINT
C30: AMP DAMPING
C40: OUTPUT MODE
C60: SELF CHECK
D10: LOW CUT
D11: LOW CUT MODE
D15: H/L SWAP
*
1
D16: H2O UNIT SEL
D20: OUT LIMIT(L)
D21: OUT LIMIT(H)
D22: REV OUTPUT
D25: BURNOUT
D26: ERROR OUT
D30: SP UNIT
*
1
D31: SP A/G SLCT
*
1
D32: ATM. PRESS*
1
D33: SP LRV
*
1
D34: SP URV
*
1
D35: SP POINT
*
1
D36: SP DAMPING
*
1
D37: SP SELECT
*
1
D40: TEMP UNIT
D50: QUICK RESP
D55: WRT PROTECT
D56: WRT ENABLE
D57: NEW PASSWORD
D58: SOFTWR SEAL
D60: SELF CHECK
E10: T. ZERO CMP
E11: TEMP ZERO
E30: BI DIRE MODE
E50: DO SELECT
*
2
E51: DO SIG.TYPE
*
2
E52: D OUTPUT
*
2
E60: SELF CHECK
G10: P AL MODE
G11: P HI. AL VAL
G12: P LO. AL VAL
G20: SP AL MODE
*
1
G21: SP HI. AL VAL
*
1
G22: SP LO. AL VAL
*
1
G30: T AL MODE
G31: T HI. AL VAL
G32: T LO.AL VAL
G50: AUTO RECOVER
G60: SELF CHECK
H10: AUTO P LRV
H11: AUTO P URV
H20: AUTO SP LRV
*
1
H21: AUTO SP URV
*
1
H60: SELF CHECK
I10: DISP OUT1
I11: DISP OUT2
I12: DISP OUT3
I13: DISP OUT4
I20: P DISP MODE
I21: PRES % RESO
I30: ENGR. UNIT
I31: EASY EU SET
I32: ENGR. EXP
I33: ENGR. LRV
I34: ENGR. URV
I35: ENGR. POINT
I40: BAR INDICATR
I41: POWER ON INF
*
3
I60: SELF CHECK
J09: ADJ UNIT
J10: ADJ PRES
J11: P ZERO ADJ
J12: P SPAN ADJ
J15: P ZERO DEV
J16: P SPAN DEV
J20: ADJ SP*
1
J21: SP ZERO ADJ*
1
J22: SP SPAN ADJ*
1
J25: SP ZERO DEV*
1
J26: SP SPAN DEV*
1
J40: OUTPUT 4mA
J41: OUTPUT 20mA
J45: AMP TEMP
J50: ADJ WHO
J51: ADJ DATE
J52: ADJ LOC
J53: ADJ DESC
J55: EXT ZERO ADJ
J56: CLEAR ADJ
J60: SELF CHECK
K10: OUTPUT X %
K40: DO TEST
*
2
K45: TEST TIME
*
3
K50: TEST KEY1
K51: TEST KEY2
K52: TEST KEY3
K53: TEST KEY4
K60: SELF CHECK
M10: SERIAL NO.
M11: MFTR. DATE
M12: EXTRA NO.
M15: SOFT REV
M16: BRAIN REV
M17: MEMO1
M18: MEMO2
M19: MEMO3
M20: ISOL MATL
M21: FILL FLUID
M22: GASKET MATL
M23: PRO CON MATL
M24: D-VENT MATL
M25: PRO CON TYPE
M26: RS ISOL MATL
M27: PRO CON SIZE
M28: NUM RS
M29: RS FILL FLID
M30: RS TYPE
M50: MS CODE 1
M51: MS CODE 2
M52: MS CODE 3
M53: MS CODE 4
M54: MS CODE 5
M55: MS CODE 6
M60: SELF CHECK
P10: ERROR REC 1
P12: ERROR REC 2
P14: ERROR REC 3
P16: ERROR REC 4
P50: REC CLEAR
P60: SELF CHECK
T10: S. C. ENABLE
T11: NUM OF POINT
T20: X START (FIX)
T21: Y START (FIX)
T22: X1
T23: Y1
T24: X2
T25: Y2
T26: X3
T27: Y3
T28: X4
T29: Y4
T30: X5
T31: Y5
T32: X6
T33: Y6
T34: X7
T35: Y7
T36: X8
T37: Y8
T38: X9
T39: Y9
T40: X END (FIX)
T41: Y END (FIX)
T60: SELF CHECK
B: SENSOR TYPE
D: AUX SET 1 E: AUX SET2 G: ALARM SET H: AUTO SET I: DISP SET
J: ADJUST K: TEST M: DEVICE INFO P: RECORD T: CHARACTERIZR
SET
ADJ
F0310.ai
*1: Available for differential pressure transmitter.
*2: Available for EJX series only.
*3: Available for software revision 2.02 or later.
Software revision can be checked by the parameter M15: SOFT REV.
