5. Parameter Summary
Instruments to which applicable:
F:Di󰀨erentialpressuretransmitters
P: Absolute and gauge pressure transmitters
L:Flangemounteddi󰀨erentialpressuretransmitters
No. Parameter name Item
*1
R/W
Content Default value
Applicable
model
Upload
data
F P L
01 MODEL Model R EJX (for EJX series)
EJA (for EJA series)
  
—
02 TAG No. Tag number R Asspecied
  
—
03 SELF CHECK Self-diagnostics R GOOD
  
—
A DISPLAY Measured data display
A10 OUTPUT Output (in %) R -2.5 to 110%
  
—
A11 PRES Measured pressure after zero
adjustment
R UnitspeciedinC20
  
—
A15 OUTPUT mA Output current R 3.600 to 21.600 mA
  
—
A16 ENGR. OUTPUT User scaled value R UnitspeciedinI30
  
—
A17 ENGR. EXP Exponents R UnitspeciedinI32
  
—
A20 SP % Static pressure (in %) R -10 to 110%

—

—
A21 SP Static pressure after zero
adjustment
R UnitspeciedinD30

—

—
A30 CAPSULE TEMP Capsule temperature R UnitspeciedinD40
  
—
A60 SELF CHECK Self-diagnostics R Refer to Table 4.1 Alarm
Message Summary
  
—
B SENSOR TYPE Sensor type
B10 MODEL Model and capsule type R Model and capsule type
  
—
B11 STYLE NO. Style number R Style number of product
  
—
B20 PRES LRL Lower range limit R UnitspeciedinC20
  
—
B21 PRES URL Upper range limit R UnitspeciedinC20
  
—
B22 P MIN SPAN Minimum span R UnitspeciedinC20
  
—
B30 SP LRL Lower range limit for static
pressure
R UnitspeciedinD30

—

—
B31 SP URL Upper range limit for static
pressure
R UnitspeciedinD30

—

—
B32 SP MIN SPAN Minimum span for static
pressure
R UnitspeciedinD30

—

—
B60 SELF CHECK Self-diagnostics R See A60
  
—
C BASIC SETUP Setting data
C10 TAG NO. Tag number W 16 alphanumeric characters Asspecied
   
C20 PRES UNIT Measurement range unit W mmH2O, mmAq, mmWG,
mmHg, Torr, kPa, MPa, mbar,
bar, gf/cm
2
, kgf/cm
2
, inH2O,
inHg, ftH2O, psi, atm, Pa, hPa
kPa
   
C21 PRES LRV Lower range value W -32000 to 32000 within
measurement range
Asspecied
   
C22 PRES URV Upper range value W -32000 to 32000 within
measurement range
Asspecied
   
C23 PRES POINT Decimal place W 0 to 4 2
   
C30 AMP DAMPING Damping time constant at
amplier
W 0.50(0.00) to 100.00 seconds ,
see D50
2.00 seconds or
asspecied
   
C40 OUTPUT MODE Output mode W LINEAR or SUQARE ROOT LINEAR or as
specied
   
C60 SELF CHECK Self-diagnostics R See A60
  
—
*1: R/W: R = Read only, W = Read & Write
*2: The default value shows MWP (Maximum working pressure) of the capsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
*3: This function cannot be used for V capsule.
*4: This parameter may contain the adjustment value at factory upon shipment. If executing J56 “CLEAR ADJ”, the value of J15, J16,
J40 and J41 will become 0, and value of J11 and J12 will become the value of PRES LRV and PRES URV respectively.
