YOKOGAWA DPharp Series User Manual

<5. Parameter Summary>
5-2
IM 01C25T03-01E
No. Parameter name Item
*1
R/W
Content Default value
Applicable
model
Upload
data
F P L
D AUX SET 1 Auxiliary setting data 1
D10 LOW CUT Low cut W 0.00 to 20.00% 10.00%
   
D11 LOW CUT MODE Low cut mode W LINEAR or ZERO LINEAR
   
D15 H/L SWAP Impulse piping accessing
direction
*3
W NORMAL or REVERSE NORMAL

—
 
D16 H2O UNIT SEL H2O unit select W @4degC or @20degC
(68.0F)
@4degC
   
D20 OUT LIMIT (L) Low side output limiter W -2.50 to 110.00% -2.50%
   
D21 OUT LIMIT (H) High side output limiter W -2.50 to 110.00% 110%
   
D22 REV OUTPUT Output reversal W NORMAL or REVERSE NORMAL
   
D25 BURNOUT CPU error R HIGH or LOW
  
—
D26 ERROR OUT Hardware error W BURNOUT DIR or HOLD BURNOUT DIR
   
D30 SP UNIT Static pressure unit W See C20 MPa

—
 
D31 SP A/G SLCT Gauge/Abs select for static
pressure
W GAUGE or ABSOLUTE ABSOLUTE

—
 
D32 ATM. PRESS Coe󰀩cientforgivengauge
pressure
W UnitspeciedinD30 0.10133 MPa

—
 
D33 SP LRV Lower limit of static pressure W -32000 to 32000 within
measurement range
0.0 MPa

—
 
D34 SP URV Upper limit of static pressure
*2
W -32000 to 32000 within
measurement range

—
 
D35 SP POINT Decimal place of static
pressure
W 0 to 4 1

—
 
D36 SP DAMPING Damping time constant of SP W 0.00 to 100.00 seconds 2.00 seconds

—
 
D37 SP SELECT H/L select for static pressure W HIGH or LOW HIGH

—
 
D40 TEMP UNIT Temperature setting unit W degC, degF, or K degC
   
D50 QUICK RESP Quick response W OFF or ON (enable 0.00 to
0.50 seconds at C30)
OFF
   
D55 WRT PROTECT Write protect indicator R NO or YES NO
  
—
D56 WRT ENABLE Write protect release W 8 alphanumeric characters None
  
—
D57 NEW PASSWORD User set password for write
protect
W 8 alphanumeric characters None
  
—
D58 SOFTWR SEAL Software seal R BREAK or KEEP KEEP
  
—
D60 SELF CHECK Self-diagnostics R See A60
  
—
E AUX SET 2 Auxiliary setting data 2
E10 T. ZERO CMP Temperature compensation
mode
W OFF or ON OFF
  
—
E11 TEMP ZERO Zero shift compensation W -99.999 to 99.999%/degC 0.000%/degC
  
—
E30 BI DIRE MODE Bidirectional mode W OFF or ON OFF
  
—
E50 DO SELECT Contact output select W INHIBIT, PRES, SP, TEMP,
PRES/SP, PRES/TEMP, SP/
TEMP, or PRES/SP/TEMP
INHIBIT
  
—
E51 DO SIG. TYPE Signal type select W OFF WHEN ALARM or ON
WHEN ALARM
ON WHEN
ALARM
  
—
E52 D OUTPUT Contact output R OFF or ON OFF
  
—
E60 SELF CHECK Self-diagnostics R See A60
  
—
*1: R/W: R = Read only, W = Read & Write
*2: The default value shows MWP (Maximum working pressure) of the capsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
*3: This function cannot be used for V capsule.
*4: This parameter may contain the adjustment value at factory upon shipment. If executing J56 “CLEAR ADJ”, the value of J15, J16,
J40 and J41 will become 0, and value of J11 and J12 will become the value of PRES LRV and PRES URV respectively.
