<5. Parameter Summary>
5-3
IM 01C25T03-01E
No. Parameter name Item
*1
R/W
Content Default value
Applicable
model
Upload
data
F P L
G ALARM SET Alarm setting
G10 P AL MODE Alert mode W INHIBIT, HI. AL DETECT, LO.
AL DETECT, or HI/LO. AL
DETECT
INHIBIT
  
—
G11 P HI. AL VAL High side alert value W -32000 to 32000, unit
speciedinC20
100.000 kPa
  
—
G12 P LO. AL VAL Low side alert value W -32000 to 32000, unit
speciedinC20
-100.000 kPa
  
—
G20 SP AL MODE Static pressure alert mode W INHIBIT, HI. AL DETECT, LO.
AL DETECT, or HI/LO. AL
DETECT
INHIBIT

—

—
G21 SP HI. AL VAL High side alert value of SP*
2
W -32000 to 32000, unit
speciedinD30

—

—
G22 SP LO. AL VAL Low side alert value of SP W -32000 to 32000, unit
speciedinD30
0.00000 MPa

—

—
G30 T AL MODE Temperature alert mode W INHIBIT, HI. AL DETECT, LO.
AL DETECT, or HI/LO. AL
DETECT
INHIBIT
  
—
G31 T HI. AL VAL High side alert value of
temperature
W -50 to 130 120 degC
  
—
G32 T LO. AL VAL Low side alert value of
temperature
W -50 to 130 -40 degC
  
—
G50 AUTO RECOVER Auto-recover from sensor error W OFF or ON ON
  
—
G60 SELF CHECK Self-diagnostics R See A60
  
—
H AUTO SET Automatic setup
H10 AUTO P LRV Lower range value auto setup W -32000 to 32000, unit
speciedinC20
Asspecied
  
—
H11 AUTO P URV Upper range value auto setup W -32000 to 32000, unit
speciedinC20
Asspecied
  
—
H20 AUTO SP LRV SP lower range value auto
setup
W -32000 to 32000, unit
speciedinD30
0.00000 MPa

—

—
H21 AUTO SP URV SP upper range value auto
setup*
2
W -32000 to 32000, unit
speciedinD30

—

—
H60 SELF CHECK Self-diagnostics R See A60
  
—
I DISP SET Display setting
I10 DISP OUT1 LCD output 1 W PRES, PRES %, ENGR.
PRES, SP, or SP %
PRES %
   
I11 DISP OUT2 LCD output 2 W PRES, PRES %, ENGR.
PRES, SP, SP %, or ---
---
   
I12 DISP OUT3 LCD output 3 W See I11 ---
   
I13 DISP OUT4 LCD output 4 W See I11 ---
   
I20 P DISP MODE % display mode W LINEAR or SQUARE ROOT LINEAR
   
I21 PRES % RESO % display resolution W NORMAL or HIGH
RESOLUTION
NORMAL
   
I30 ENGR. UNIT User set engineering unit W 8 alphanumeric characters
   
I31 EASY EU SET Engineering unit select W
  
—
I32 ENGR. EXP Exponents W ---, ×10, ×100, ×1000 ---
   
I33 ENGR. LRV User set lower range limit W -32000 to 32000, unit
speciedinI30
0.00
   
I34 ENGR. URV User set upper range limit W -32000 to 32000, unit
speciedinI30
100.00
   
I35 ENGR. POINT Decimal place of user set W 0 to 4 1
   
I40 BAR INDICATR Bar indicator W OFF or ON ON
   
I41 POWER ON INF Display when powering on W OFF or ON ON
  
—
I60 SELF CHECK Self-diagnostics R See A60
  
—
*1: R/W: R = Read only, W = Read & Write
*2: The default value shows MWP (Maximum working pressure) of the capsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
*3: This function cannot be used for V capsule.
*4: This parameter may contain the adjustment value at factory upon shipment. If executing J56 “CLEAR ADJ”, the value of J15, J16,
J40 and J41 will become 0, and value of J11 and J12 will become the value of PRES LRV and PRES URV respectively.
