YOKOGAWA DPharp Series User Manual

<5. Parameter Summary>
5-4
IM 01C25T03-01E
No. Parameter name Item
*1
R/W
Content Default value
Applicable
model
Upload
data
F P L
J ADJUST Adjusting data
J09 ADJ UNIT Pressure adjusting unit select W % or PRES UNIT PRES UNIT
  
—
J10 ADJ PRES Adjustment reference pressure R UnitspeciedinJ09
  
—
J11 P ZERO ADJ Automatic zero adjustment W -32000 to 32000, unit
speciedinJ09
0.00000 kPa
*4
  
—
J12 P SPAN ADJ Automatic span adjustment W -32000 to 32000, unit
speciedinJ09
100.000 kPa
*4
  
—
J15 P ZERO DEV Manual zero adjustment W -32000 to 32000, unit
speciedinJ09
0 kPa
*4
  
—
J16 P SPAN DEV Manual span adjustment W -32000 to 32000, unit
speciedinJ09
0 kPa
*4
  
—
J20 ADJ SP Adjustment reference pressure
of SP
R UnitspeciedinJ09

—

—
J21 SP ZERO ADJ Automatic SP zero adjustment W -32000 to 32000, unit
speciedinJ09
0.00000 MPa

—

—
J22 SP SPAN ADJ Automatic SP span
adjustment*
2
W -32000 to 32000, unit
speciedinJ09

—

—
J25 SP ZERO DEV Manual SP zero adjustment W -32000 to 32000, unit
speciedinJ09
0.00000 MPa

—

—
J26 SP SPAN DEV Manual SP span adjustment W -32000 to 32000, unit
speciedinJ09
0.00000 MPa

—

—
J40 OUTPUT 4mA 4 mA adjustment W -10.000 to 10.000% 0.000%
*4
  
—
J41 OUTPUT 20mA 20 mA adjustment W -10.000 to 10.000% 0.000%
*4
  
—
J45 AMP TEMP Ampliertemperature R UnitspeciedD40 0 degC
  
—
J50 ADJ WHO Adjustment information W 8 alphanumeric characters
  
—
J51 ADJ DATE Adjustment information W 16 alphanumeric characters
  
—
J52 ADJ LOC Adjustment information W 8 alphanumeric characters
  
—
J53 ADJ DESC Adjustment information W 16 alphanumeric characters
  
—
J55 EXT ZERO ADJ External zeroing permission W INHIBIT or ENABLE ENABLE
  
—
J56 CLEAR ADJ Clear adjustment W ---, PRES, SP, 4-20mA, or
ALL
---
  
—
J60 SELF CHECK Self-diagnostics R See A60
  
—
K TEST Test parameters
K10 OUTPUT X % Test output % setting W Within a range between D20
and D21
0.00%
  
—
K40 DO TEST Test contact output W OFF or ON OFF
  
—
K45 TEST TIME “OUTPUT X %” and “DO
TEST” duration time selection
W 10 min, 30 min, 60 min,
3 hour, 6 hour, 12 hour
10 min
  
—
K50 TEST KEY1 Special maintenance
parameter
W
  
—
K51 TEST KEY2 Special maintenance
parameter
W
  
—
K52 TEST KEY3 Special maintenance
parameter
W
  
—
K53 TEST KEY4 Special maintenance
parameter
W
  
—
K60 SELF CHECK Self-diagnostics R See A60
  
—
M DEVICE INFO Device information
M10 SERIAL NO. Serial number R
  
—
M11 MFTR. DATE Manufactured date R
  
—
M12 EXTRA NO. Customization number R
  
—
M15 SOFT REV Software revision R
  
—
M16 BRAIN REV BRAIN protocol revision R
  
—
M17 MEMO1 Memo W 16 alphanumeric characters
  
—
M18 MEMO2 Memo W 16 alphanumeric characters
  
—
M19 MEMO3 Memo W 16 alphanumeric characters
  
—
*1: R/W: R = Read only, W = Read & Write
*2: The default value shows MWP (Maximum working pressure) of the capsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
*3: This function cannot be used for V capsule.
*4: This parameter may contain the adjustment value at factory upon shipment. If executing J56 “CLEAR ADJ”, the value of J15, J16,
J40 and J41 will become 0, and value of J11 and J12 will become the value of PRES LRV and PRES URV respectively.
