YOKOGAWA DPharp Series User Manual

<5. Parameter Summary>
5-5
IM 01C25T03-01E
No. Parameter name Item
*1
R/W
Content Default value
Applicable
model
Upload
data
F P L
M20 ISOL MATL Capsule material W
  
—
M21 FILL FLUID Filluid W
  
—
M22 GASKET MATL Gasket material W
  
—
M23 PRO CON MATL Flange material W
  
—
M24 D-VENT MATL Vent plug material W
  
—
M25 PRO CON TYPE Process connection type W
  
—
M26 RS ISOL MATL Remote seal material W
  
—
M27 PRO CON SIZE Flange size W
  
—
M28 NUM RS Number of remote seal W
  
—
M29 RS FILL FLUID Filluidofremoteseal W
  
—
M30 RS TYPE Remote seal type W
  
—
M50 MS CODE 1 Modelandsu󰀩xcode1 W
  
—
M51 MS CODE 2 Modelandsu󰀩xcode2 W
  
—
M52 MS CODE 3 Modelandsu󰀩xcode3 W
  
—
M53 MS CODE 4 Modelandsu󰀩xcode4 W
  
—
M54 MS CODE 5 Modelandsu󰀩xcode5 W
  
—
M55 MS CODE 6 Modelandsu󰀩xcode6 W
  
—
M60 SELF CHECK Self-diagnostics R See A60
  
—
P Record History of errors
P10 ERROR REC 1 Last error W See A60 GOOD
  
—
P12 ERROR REC 2 Second recent error W See A60 GOOD
  
—
P14 ERROR REC 3 Third recent error W See A60 GOOD
  
—
P16 ERROR REC 4 Forth recent error W See A60 GOOD
  
—
P60 SELF CHECK Self-diagnostics R See A60
  
—
T CHARACTERIZR Signal characterizer setting
T10 S. C. ENABLE Signal characterizer permission W INHIBIT or ENABLE INHIBIT
  
—
T11 NUM OF POINT Number of coordinates W 0 to 9 0
  
—
T20 X START (FIX) Start point of X R 0.00%
  
—
T21 Y START (FIX) Start point of Y R 0.00%
  
—
T22 X1 Coordinate 1 of X W 0.00 to 100.00% 10.00
  
—
T23 Y1 Coordinate 1 of Y W 0.00 to 100.00% 10.00
  
—
T24 X2 Coordinate 2 of X W 0.00 to 100.00% 20.00
  
—
T25 Y2 Coordinate 2 of Y W 0.00 to 100.00% 20.00
  
—
T26 X3 Coordinate 3 of X W 0.00 to 100.00% 30.00
  
—
T27 Y3 Coordinate 3 of Y W 0.00 to 100.00% 30.00
  
—
T28 X4 Coordinate 4 of X W 0.00 to 100.00% 40.00
  
—
T29 Y4 Coordinate 4 of Y W 0.00 to 100.00% 40.00
  
—
T30 X5 Coordinate 5 of X W 0.00 to 100.00% 50.00
  
—
T31 Y5 Coordinate 5 of Y W 0.00 to 100.00% 50.00
  
—
T32 X6 Coordinate 6 of X W 0.00 to 100.00% 60.00
  
—
T33 Y6 Coordinate 6 of Y W 0.00 to 100.00% 60.00
  
—
T34 X7 Coordinate 7 of X W 0.00 to 100.00% 70.00
  
—
T35 Y7 Coordinate 7 of Y W 0.00 to 100.00% 70.00
  
—
T36 X8 Coordinate 8 of X W 0.00 to 100.00% 80.00
  
—
T37 Y8 Coordinate 8 of Y W 0.00 to 100.00% 80.00
  
—
T38 X9 Coordinate 9 of X W 0.00 to 100.00% 90.00
  
—
T39 Y9 Coordinate 9 of Y W 0.00 to 100.00% 90.00
  
—
T40 X END (FIX) End point of X R 100.00%
  
—
T41 Y END (FIX) End point of Y R 100.00%
  
—
T60 SELF CHECK Self-diagnostics R See A60
  
—
*1: R/W: R = Read only, W = Read & Write
*2: The default value shows MWP (Maximum working pressure) of the capsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
*3: This function cannot be used for V capsule.
*4: This parameter may contain the adjustment value at factory upon shipment. If executing J56 “CLEAR ADJ”, the value of J15, J16,
J40 and J41 will become 0, and value of J11 and J12 will become the value of PRES LRV and PRES URV respectively.
