YOKOGAWA DPharp Series User Manual

<3. Operation>
3-22
IM 01C25T03-01E
(21) Adjustment Information and User
Memo Fields
(J50: ADJ WHO, J51: ADJ DATE, J52:
ADJ LOC, J53: ADJ DESC, M17 to M19:
MEMO1 to MEMO3)
Thisfeatureprovidesfoureldsforinstrument
adjustment information at maintenance: inspection
date, inspector, location, and description. Also three
usermemoeldsareprovided,eachholdingupto
16 alphanumeric characters.
• Example: Save an inspection date of October
21, 2003.
DATA DIAG PRNT ESC
SET
J51:ADJ DATE
MM-DD-YYYY
10-21-2003
ESCCODE CAPS CLR
PARAM
J50:ADJ WHO
J51:ADJ DATE
J52:ADJ LOC
Set “10-21-2003” in the order of
month, day, and year.
Press the key twice to
enter the setting.
F0355.ai
3.3 Displaying Data Using the
BT200
3.3.1 Displaying Measured Data
The BT200 can be used to display measured data.
The measured data is updated automatically
every seven seconds. In addition, the display can
be updated to the present data value at any time
by pressing the (DATA) key. For parameters
associated with the display of measured data, see
chapter 5 Parameter Summary.
• Example: Display output.
DATA DIAG PRNT ESC
HOME SET ADJ ESC
F0356.ai
Data is updated automatically
at 7-second intervals.
Display “A10: OUTPUT.”
communi
PARAM
A10:OUTPUT
0.0 %
A11:PRES
0.0000 kPa
A15:OUTPUT mA
4.000 mA
PARAM
A10:OUTPUT
0.0 %
A11:PRES
0.0000 kPa
A15:OUTPUT mA
4.000 mA
MENU
A:DISPLAY
B:SENSOR TYPE
C:BASIC SETUP
D:AUX SET1
E:AUX SET2
G:ALARM SET
3.3.2 Display Transmitter Model and
Specications
The BT200 can be used to display the model and
specicationsofthetransmitter.
• Example: View transmitter model name.
HOME SET ADJ ESC
DATA DIAG PRNT ESC
PARAM
B10:MODEL
EJX110 M
B11:STYLE NO.
1.00
B20:PRES LRL
- 98.07 kPa
Press .
F0357.ai
For the associated
parameters, see Chapter 5,
Parameter Summary.
MENU
A:DISPLAY
B:SENSOR TYPE
C:BASIC SETUP
D:AUX SET1
E:AUX SET2
G:ALARM SET
