2-3
IM WT1801-01EN
Settings of Elements Grouped in a Wiring Unit
If independent input element configuration is off and a wiring system other than 1P2W is selected when the
measurement range, valid measurement range, or valid synchronization source settings of each input element
are different, these settings are changed in the manner described below:
•
The measurement range is set to the greatest of the measurement ranges of the input elements assigned to
the same wiring unit. The external current sensor input range has precedence over the direct input current
range.
• The auto range on/of
f settings are changed to match the setting of the input element whose measurement
range is highest. If multiple input elements are set to a common highest measurement range, the setting of
the input element with the smallest input element number takes precedence.
• In the valid measurement range settings, all measurement ran
ges are enabled (selected).
• The synchronization source for a wiring unit is set to the input element whose number is the smallest of the
elements in the unit.
At the same time that you press ELEMENT to select the element that you want to set the voltage or current
range of, the indicators for the input elements that have been assigned to the same wiring unit illuminate.
Wiring System during High Speed Data Capturing
2 Fundamental Measurement Conditions
To Next Page
