Page – 64/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
SET OPTIONS
Parameter Allowable range Description
AUX OUT FUNCTION
(A)
NONE, BRAKE This parameter enables or disables the NEB output (A4),
dedicated to the electromechanical brake.
NONE = Diagnoses are masked and E.B. is not driven
upon a traction request.
BRAKE = E.B. is driven upon a traction request if all
the related diagnoses pass. The behavior on a slope
depends on the STOP ON RAMP setting.
Do not use this setting if the electromechanical
brake is not really present.
Note: in applications with two controllers driving two
traction motors and only one E.B., this parameter has to be
set on BRAKE only in the controller that drives the E.B. .
SYNCRO
(CO)
OFF ÷ ON This parameter enables or disables the syncro message.
OFF = The syncro message is not used.
ON = The syncro message is enabled.
AUTO PARK BRAKE
(CO)
OFF ÷ ON This parameter enables or disables the autonomous
management of the brake.
OFF = E.B. is activated or deactivated according to the
signal received via CAN bus.
ON = E.B. is managed by the controller itself ignoring
any activation/deactivation signal received via CAN
bus.
AUTO LINE CONT.
(CO)
OFF ÷ ON This parameter enables or disables the autonomous
management of the main contactor.
OFF = Main contactor is opened or closed according to
the signals received by CAN bus.
ON = Main contactor is managed by the controller itself
ignoring any activation/deactivation signal received via
CAN bus.
ACCEL MODULATION
(T, TM, P, CO)
OFF ÷ ON This parameter enables or disables the acceleration-
modulation function.
OFF = The acceleration rate is inversely proportional to
the ACCEL DELAY parameter.
ON = The acceleration ramp is inversely proportional to
the ACCEL DELAY parameter only if speed setpoint is
greater than 100 Hz. Below 100 Hz the acceleration
ramp is also proportional to the speed setpoint, so that
the acceleration duration results equal to ACCEL
DELAY.
See paragraph 9.4.
EVP TYPE
(A)
NONE ÷ DIGITAL This parameter defines the behavior of output EVP1 (A24).
NONE = Output A24 is not enabled.
ANALOG = Output A24 manages a PWM-modulated
current-controlled proportional valve.
DIGITAL = Output A24 manages an on/off valve.
To Next Page
