Page – 80/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
TESTER (Master µC)
Parameter
Unit of measure
(resolution)
Description
DI4-A31 BW SW
(T, TM)
OFF/ON Status of the backward input (pin A31).
DI4-A31 BW-INCH
(TS)
OFF/ON Status of the backward input (pin A31), when the inching
function is enabled.
DI5-A19 HORN
(not for BLE0)
(T, TM)
OFF/ON Status of the digital input 5 (pin A19), dedicated to the horn
(not for BLE0).
DI5-A19 LOWER DC
(only for BLE0)
(T, TM)
OFF/ON Status of the digital input 5 (pin A19), dedicated to the
lower function done through a descent proportional valve
on A24 (only for BLE0).
DI6-A20 LOWER DC
(not for BLE0)
(T, TM)
OFF/ON Status of the digital input 6 (pin A20), dedicated to the
lower function done through a descent proportional valve
on A24 (not for BLE0).
DI7-A35 LFT/E DC
(only for COMBIAC0)
(T, TM)
OFF/ON Status of the digital input 7 (pin A35), dedicated to the lift
function (only for COMBIAC0).
DI7-A35 ENAB. DC
(T, TM)
OFF/ON Status of the digital input 7 (pin A35) dedicated to the
enable function (only for ACE0).
DI8-A17 SPD1 DC
(T, TM)
OFF/ON Status of the spare digital input 8 (pin A17).
DI9-A29 PURID DC
(T, TM)
OFF/ON Status of the digital input 9 (pin A29).
DI10-A16 SPD2 DC
(T, TM)
OFF/ON Status of the spare digital input 10 (pin A16).
DI11-A18 CUTBAC1
(T, TM)
OFF/ON Status of the spare digital input 11 (pin A18).
DI12-A21 CUTBAC2
(T, TM)
OFF/ON Status of the spare digital input 12 (pin A21).
DI0-A1 SEAT SW
(P)
OFF/ON Status of the TILLER/SEAT input (pin A1).
DI1-A7 SPD1 SW
(P)
OFF/ON Status of the digital input 1 (pin A7), dedicated to the 1
st
pump speed (for ACE0/COMBIAC0 configured as pump
controller).
