8 - 12
DS3408 Product Reference Guide
Convert Case
Enable this to c
onvert all ba
r code da
ta to the selected
case.
USB Static CDC
When disabled, each device conne
cted consum
es another COM port (first device = COM1,
second device = COM2, th
ird device =
COM3, etc.)
When enabled
, each dev
ice connec
ts to the same CO
M port.
*No Case Conversion
Convert All to Upper Case
Convert All t
o Lower Ca
se
*Enable USB S
t
atic CDC
Disable USB St
atic CDC
129
131
