Symbologies
13 - 29
Enable/Disable GS1-128 (formerly UCC/EAN-128)
Parameter # 0Eh
T
o enable or disable GS1-1
28, scan the appropr
iate bar code below
.
Enable/Disable ISBT 128
Parameter # 54h
ISBT 128 is a variant of Code 128 used in the blood bank
industry
. Scan a bar code belo
w to enable or disable
ISBT 128. If necessary
, th
e host must perform concatenation of th
e ISBT data.
*
Enable GS1-
128
(01h)
Disable
GS1-1
28
(00h)
*Enable ISBT 128
(01h)
Disable ISBT 128
(00h)
198
200
