Zebra DS4308 Reference Guide

Name: Zebra DS4308
Brand: Zebra
Rating: 4 (1 reviews)

436 pages

To Next Page

To Previous Page

8 - 22 DS3408 Product Reference Guide

7006 Pause

7007 Scroll Lock

7008 Backspace

7009 Tab

7010 Print Screen

7011 Insert

7012 Home

7013 Enter

7014 Escape

7015 Up Arrow

7016 Down Arrow

7017 Left Arrow

7018 Right Arrow

Table 8-7

USB Extended Keypad Character Set (Continued)

Extended Keypad Keystroke

Revision History5
Table of Contents7
About This Guide17
- Introduction17
- Configurations17
- Chapter Descriptions17
- Notational Conventions18
- Related Documents19
- Service Information19
Getting Started21
- Introduction21
- Unpacking22
- Setting Up the Digital Scanner22
Scanning25
- Introduction25
- LED Definitions28
Maintenance and Technical Specifications41
- Introduction41
- Maintenance41
- Troubleshooting42
- Technical Specifications44
User Preferences49
- Introduction49
- Errors While Scanning50
- User Preferences Parameter Defaults50
Decoding Preferences65
- Introduction65
Keyboard Wedge Interface71
- Introduction71
- Connecting a Keyboard Wedge Interface72
RS-232 Interface95
- Introduction95
USB Interface119
- Introduction119
- Connecting a USB Interface120
- USB Parameter Defaults121
IBM 468X/469X Interface141
- Introduction141
  - Port Address144
Wand Emulation Interface147
- Introduction147
- Connecting Using Wand Emulation148
  - Wand Emulation Host Types150
  - Ignore Unknown Characters152
Scanner Emulation Interface155
- Introduction155
- Connecting Using Scanner Emulation156
  - Beep Style159
  - Convert All Bar Codes to Code 39162
123 Scan169
- Introduction169
- Communication with 123Scan169
- 123Scan Parameter169
Symbologies171
- Introduction171
- Scanning Sequence Examples171
- Errors While Scanning172
- Symbology Parameter Defaults172
- Code 128196
- Code 93210
  - Enable/Disable Code 93210
  - Code 11213
- Interleaved 2 of 5 (ITF)217
- Matrix 2 of 5232
- Report Version260
  - Flush Macro Buffer261
  - Abort Macro PDF Entry261
Miscellaneous Scanner Options263
- Introduction263
- Scanning Sequence Examples263
- Errors While Scanning264
- Miscellaneous Scanner Parameter Defaults264
  - Transmit Code ID Character265
Advanced Data Formatting273
- Introduction273
- Rules: Criteria Linked to Actions273
- ADF Bar Code Menu Example274
- ADF Bar Codes277
Standard Default Parameters379
Programming Reference389
- Symbol Code Identifiers389
Sample Bar Codes397
- Code 39397
- UPC/EAN397
  - UPC-A, 100 %397
  - EAN-13, 100 %398
- Code 128398
- Interleaved 2 of 5398
- GS1 DataBar-14398
- PDF417399
- Data Matrix399
- Maxicode399
- QR Code400
- US Postnet400
- UK Postal400
Numeric Bar Codes401
- Numeric Bar Codes401
- Cancel403
ASCII Character Sets405
Tell Us What You Think...433

Other manuals for Zebra DS4308

Quick Start Guide20 pages

Product Reference Guide520 pages

Questions and Answers:

Need help?

Do you have a question about the Zebra DS4308 and is the answer not in the manual?

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
