Zebra DS4308 Reference Guide

Name: Zebra DS4308
Brand: Zebra
Rating: 4 (1 reviews)

436 pages

To Next Page

To Previous Page

Advanced Data Formatting 15 - 17

Code Types (continued)

UPC/EAN Composites

GS1 DataBar and GS1-128 Composites

Aztec

Aztec Rune

NOTE When selecting composite bar codes, enable AIM IDs if parsing UPC or EAN composite data, or data from

an application that uses symbol separators.
