Maintenance and Technical Specifications 3 - 5
Pitch Tolerance ± 60° from normal
Roll Tolerance ± 180° from normal
Print Contrast Minimum 25% minimum reflectance differential, measured at 650 nm.
Ambient Light Immunity 10,000 Ft Candles (107,600 Lux)
Durability 6.5 ft (2 m) drop to concrete
Operating Temperature -4° to 122° F (-20° to 50° C)
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95% (non-condensing)
Weight (without cable) 11.73 oz. (335 g)
Dimensions:
Height
Width
Depth
7.34 in. (18.65 cm)
4.82 in. (12.25 cm)
2.93 in. (7.43 cm)
Laser 650nm laser diode
ESD 15 kV area discharge
8 kV contact discharge
Minimum Element Width 5 mil (0.127 mm)
Interfaces Supported RS-232, Keyboard Wedge, Wand Emulation, Scanner Emulation,
IBM 468X/469X, USB, Synapse
Table 3-2
Technical Specifications (Continued)
Item Description
