Page #142 background imageLoading...
Page #142 background image
Data Capture
142
DataWedge
DataWedge is a utility that adds advanced barcode scanning capability to any application without writing code.
It runs in the background and handles the interface to built-in barcode scanners. The captured barcode data is
converted to keystrokes and sent to the target application as if it was typed on the keypad.
To configure DataWedge refer to the device Integrator Guide.
Enabling DataWedge
1. Swipe up from the bottom of the Home screen and touch .
2. Touch > Settings.
3. Touch the DataWedge enabled checkbox. A blue checkmark appears in the checkbox indicating that
DataWedge is enabled.
4. Touch .
Disabling DataWedge
1. Swipe up from the bottom of the Home screen and touch .
2. Touch > Settings.
3. Touch the DataWedge enabled checkbox. A blue checkmark disappears from the checkbox indicating that
DataWedge is disabled.
4. Touch .

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra TC77 and is the answer not in the manual?

Zebra TC77 Specifications

General IconGeneral
Display diagonal4.7 \
Touch technologyDual-touch
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Flash memory32 GB
Internal memory4 GB
Internal memory type-
Compatible memory cardsMicroSD (TransFlash), SD, SDHC, SDXC
Number of cores8
Processor familySnapdragon
Processor frequency2.2 GHz
Processor manufacturerQualcomm
Operating system version8.1
Operating system installedAndroid
Data network2G, 3G, EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
GSM bands supported850, 900, 1800, 1900 MHz
Security algorithmsAES, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Rear camera resolution (numeric)13 MP
USB 2.0 ports quantity1
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)5 - 90 %
Battery voltage3.7 V
Battery capacity4620 mAh
CertificationWFA (802.11n, WMM-PS, 801.11ac, PMF)
Product colorBlack, Silver
Linear (1D) barcodes supportedCode 39
International Protection (IP) codeIP65, IP68
Harmonized System (HS) code84713000
Weight and Dimensions IconWeight and Dimensions
Depth28 mm
Width84 mm
Height161 mm
Weight376 g
