Using the Device
54
Status Icons
Table 5 Status Icons
Icon Description
Alarm is active.
Main battery is fully charged.
Main battery is partially drained.
Main battery charge is low.
Main battery charge is very low.
Main battery is charging.
All sounds, except media and alarms, are silenced and vibrate mode is active.
Do Not Disturb mode active.
Airplane Mode is active. All radios are turned off.
Bluetooth is on.
The device is connected to a Bluetooth device.
Connected to a Wi-Fi network.
Not connected to a Wi-Fi network or no Wi-Fi signal.
Connected to an Ethernet network.
Speakerphone enabled.
Portable Wi-Fi hotspot is active (WWAN only).
Connected to a 4G LTE/LTE-CA network (WWAN only)
1
.
Connected to a DC-HSPA, HSDPA, HSPA+, HSUPA, LTE/LTE-CA or WCMDMA network
(WWAN only)
1
.
Connected to a 1x-RTT (Sprint), EGDGE, EVDO, EVDV or WCDMA network (WWAN only)
1
.
Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network (WWAN only)
1
.
Connected to an EDGE network (WWAN only)
1
.
Connected to a GPRS network (WWAN only)
1
.
1
Cellular network icon that appears is dependent upon the carrier/network.
