Zebra TC77 User Manual

194
Wireless
Introduction
This section provides information on the wireless features:
• Wireless Wide Area Network (WWAN, TC77 only)
• Wireless Local Area Network (WLAN)
• Bluetooth
• Near Field Communications (NFC)
•Cast.
Wireless Wide Area Networks
Use Wireless wide area networks (WWANs) to access data over a cellular network. This section
provides information on:
• Sharing a data connection
• Monitoring data usage.
• Changing Cellular Network settings
• Locking a SIM card.
Sharing the Mobile Data Connection
The Tethering & Portable Hotspot settings allows sharing the mobile data connection with a single
computer via USB tethering or Bluetooth tethering. Share the data connection with up to eight devices
at once, by turning it into a portable Wi-Fi hotspot. While the device is sharing its data connection, an
icon displays at the top of the screen and a corresponding message appears in the notification list.
Enabling USB Tethering
NOTE: USB tethering is not supported on computers running Mac OS. If the computer is running Windows or a
recent version of Linux (such as Ubuntu), follow these instructions without any special preparation. If running a ver
-
sion of Windows that precedes Windows 7, or some other operating system, you may need to prepare the computer
to establish a network connection via USB.
1. Connect the device to a host computer with the USB cable.
2. The notification USB charging this device appears in the Notifications panel.
3. Swipe down from the Status bar to open the Quick Access panel and then touch .

Zebra TC77 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), SD, SDHC, SDXC
Number of cores	8
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system version	8.1
Operating system installed	Android
Data network	2G, 3G, EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Certification	WFA (802.11n, WMM-PS, 801.11ac, PMF)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP65, IP68
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
