Getting Started
37
11.Replace the access door.
Figure 44 Replace Access Door
12.Press the access door down and ensure that it is properly seated.
CAUTION: Access door must be replaced and securely seated to ensure proper device sealing.
13.If the device has a secure access door, use a Microstix 0 screwdriver to install the 3ULR-0 screw.
Figure 45 Replace Secure Access Door Screw
14.Insert the battery, bottom first, into the battery compartment in the back of the device.
15.Press the battery down until the battery release latch snaps into place.
16.Replace the hand strap, if required.
17.Press and hold the Power button to turn on the device.
Replacing the microSD Card
To replace the microSD card:
1. Press the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
