Zebra TC77 - Page 26

Getting Started
26
2. If the device has a secure access door, use a Microstix 0 screwdriver to remove the 3ULR-0 screw.
Figure 18 Remove Secure Access Door Screw
3. Lift the access door.
Figure 19 Remove Access Door
4. Slide the microSD card holder to the Open position.
Figure 20 Open microSD Card Holder
