Getting Started
35
4. If hand strap is attached, slide the hand strap clip up toward the top of the device and then lift.
Figure 37 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the device.
7. If the device has a secure access door, use a Microstix 0 screwdriver to remove the 3ULR-0 screw.
Figure 38 Remove Secure Access Door Screw
8. Lift the access door.
Figure 39 Remove Access Door
