Safety, Installation and Operations Manual – Translation of original instructions


Model

Product designation
ZU = Zenit UNIQA
Construction material
G = Cast iron
B = Bronze
X = Stainless steel
Type of impeller
OC = open channel
CC = closed channel
V = vortex
GR = Grinder
HP = High head
CP, CT = Channel with chopper system
Outlet diameter in mm
Hydraulic variant
Power in kW
Motor poles
Motor variant
Operating mode
D = dry
W = wet
Nominal diameter of impeller (in mm)
Type of installation and anges drilling
Electrical variant
Cable lenght (m)
Rated voltage (V)
Starting
D = DOL (Direct on line)
Y = star/delta
Frequency
5 = 50Hz
6 = 60Hz
Certication
NN = standard
EX = ATEX, ATEX + IECEx
CX = IECEX only
Customization
BB 10 400 D5 EX NN
2.6 
Decal identifying surfaces with high
temperature risk
Silver sticker.
Reproduces the nameplate affixed to
the product.
It must be stuck into the space provided
in this manual and be referred to when
making any requests or enquiries.
Decal indicating correct impeller rota-
tion direction (viewed from above)
Sticker applied to the production
packaging
EN
ZUG V 100 A 15/2 A W 160 XA
21 3 4 5 6 7 8
9

11
2
1
3
4
5
6
7
8
9

11
12
13
14
15
16
17
18
12 13 14 15 16 17 18
TOP VIEW
C
O
R
R
E
C
T
S
P
I
N
C
O
U
N
T
E
R
K
I
C
K
Zenit Italia s.r.l.
Via dell’Industria, 11
I-41018 S.Cesario s.P. - MO
20m
S1 Continuous
IEC/EN 60034-1
YW Kg
TYPE S.N.
VERS
I.CL. HP2 kW
%
T amb max
°C
cos φ
V V Hz
rpmA A
IP68
m mH
max
Ø imp.
Hmin
l/s l/sQmin Qmax
3
η mot
Class I
Made in Italy
zenit.com
Ø
imp
η
imp
T
max
IP
V
Δ
Rpm
Hz
A
Δ
cos φ
~
I.CL
kW
μF
mm
l/sl/s
CEI EN 60034-1
Made in Italy
Serial number
Price list code
V
Y
A
Y
S.N.
Kg
www.zenit.com
Quality
check
3 D 
