Submasters
Page 108 Solution & Solution XL Operating Manual – Issue 1.0
The various fields in the Submasters Window (monitor) are as follows:
No – The submaster number in the form “Page # – Submaster #” (eg 1-1).
Submasters with Scenes are suffixed with an „S‟. Submasters with Chases are
suffixed with a „C‟. Unprogrammed submasters are suffixed with a „*‟.
Name – User defined name for the submaster (optional) or name of
transferred memory or range of transferred memories.
Step - The current step number – Direct Chase or transferred Chase memory
only.
Fade Up – The Intensity fade up time for the submaster.
Fade Down – The Intensity fade down time for the submaster.
Colour Fade – The Colour fade time for the submaster. Note - the Colour
Fade or Beamshape Fade or Position Fade is displayed in the window to
avoid cluttering up the screen. Use the COLOUR, BEAMSHAPE or POSITION
keys on the front panel to select which of the fade times is displayed.
Comments – This field contains additional information on the submaster:
Flash Button Action
LTP Trigger Level
Submaster Controls - if the submaster fader controls CBPE parameters.
Transferred range of memories – the first, current, next and last memory
numbers.
Macro data – number of macro triggered by the submaster.
Chase Modifiers - Direct Chase or transferred Chase memory only.
Submaster Setup Window
The Submaster Setup Window allows you to do the following:
Adjust the fade times assigned to the submaster.
Set the Flash button action.
Set the LTP Trigger Level.
Enable or disable Page Lock.
Submaster Controls – Fade CBPE (Colour, Beamshape, Position,
Effects).
Run a macro when the submaster fader is raised.
Adjust the modifiers for a direct or transferred chase.
The data that is editable via the Submaster Setup Window is displayed in the
Comments field of the Submasters Window.
