Introduction
10 025-9227S
Figure 2: Typical Model 4010 System Layout
Figure 3: Model 4010R
The Model 4010R Radio Dispatch Console has the same functions and capabilities as the
desktop Model 4010. Whereas the Model 4010 is a desktop console, the Model 4010R is a
rackmount console designed to be mounted into a rack or furniture with a built-in rack
mount compatible system.
In this manual both the Model 4010 and 4010R are referred to as the Model 4010 unless
specifically stated otherwise.
RADIO
D
RADIO
C
RADIO
B
RADIO
A
Model 4010
Radio
Dispatch
Console
Telephone Style
25 Pair Cable,
10 Feet Long
Channel
Punch-Down
Block
To Next Page
