ZETRON 4010 - Protected Punch-Down Block Configuration

Console Installation
36 025-9227S
Protected Punch-Down Block Configuration
PROTECTOR MODULE
BUSBAR ASSEMBLY
TERMINAL PLATE
ASSEMBLY
QUICK CONNECT
TAB
BOX LUG
GROUND
WIRE
JUMPER
RECEPTACLE
INCOMING LINES
MODEL
4010
SECONDARY
PROTECTION
PRIMARY
PROTECTION
OUTSIDE
LINES
TERMINAL PLATE
CONNECTION
OVERALL CONFIGURATION
PROTECTED PUNCH-DOWN BLOCK
MODEL 4010 INSTALLATION
PROTECTED PUNCH-DOWN BLOCK
024-0109A
(ONE FOR EACH PAIR TO BE
PROTECTED, 12 SUPPLIED)
#6 GROUND BUS (CFE)
25 PAIR
TELCO CABLE
(FURNISHED)
GROUNDING BUS
INCOMING LINES
_____________
TO MODEL 4010
TO MODEL 4010
ABCD
ABCD
Chan A. PTT -
Chan A. PTT +
Analog Gnd
Chan A. Record
Ground
Chan A. Aux Output
Chan A. Tx -
Chan A. Tx +
Chan A. Rx -
Chan A. Rx +
Chan A. X-Busy Out
Chan A. X-Busy In
Chan B. PTT -
Chan B. PTT +
Analog Gnd
Chan B. Record
V+
Chan B. Aux Output
Chan B. Tx -
Chan B. Tx +
Chan B. Rx -
Chan B. Rx +
Chan B. X-Busy Out
Chan B. X-Busy In
Chan C. PTT -
Chan C. PTT +
Analog Gnd
Chan C. Record
Ground
Chan C. Aux Output
Chan C. Tx -
Chan C. Tx +
Chan C. Rx -
Chan C. Rx +
Chan C. X-Busy Out
Chan C. X-Busy In
Chan D. PTT -
Chan D. PTT +
Analog Gnd
Chan D. Record
V+
Chan C. Aux Output
Chan D. Tx -
Chan D. Tx +
Chan D. Rx -
Chan D. Rx +
Chan D. X-Busy Out
Chan D. X-Busy In
Chassis
Chassis
26
1
27
2
28
3
29
4
30
5
31
6
32
7
33
8
34
9
35
10
36
11
37
12
38
13
39
14
40
15
41
16
42
17
43
18
44
19
45
20
46
21
47
22
48
23
49
24
50
25
FOUR CHANNELS
_____________
TO MODEL
4010
Punch-Down Block P/N 950-9351
