11
Manuals
Figure 4: Model 4115B
The Model 4115B Console Expander is a rackmount 60-button panel used to expand the
number of programmable keys available to the Model 4010 and Model 4010R.
Manuals
Several manuals describe the operation, installation, service, and programming of the
Model 4010. This manual describes the installation of the Model 4010. Below is a list of
the manuals and a description of their contents.
Manual Title
Part
Number
Description
Operator Manual 025-9226 Presents an overview of the console panels, a
description of the functions of each button, and a
detailed description of the Model 4010.
Installation and
Programming Manual
025-9227 Presents a description of how to install, configure, and
program the Model 4010 console and accessories.
