ZETRON 4010 - Console Power Requirements; Power Supply (802-0092) Specifications; Physical Specifications

13
Specifications
Console Power Requirements
Power Supply (802-0092) Specifications
Physical Specifications
Tone Control 15 standard tones supported
programmable (no trimmer adjustment) 650 to 2050 Hz
High Level Guard Tone duration 120/600 mSec
Function Tone Duration 40 mSec
Guard Tone Frequency 2175 Hz
Tone frequency accuracy +/- 0.2%; timing accuracy +/-1.0%
Local Control PTT normally open relay contact rated 1.0 A at 24 V
AC/DC
E & M Control TX control via PTT relay, external 48V required
Busy Channel Detect Local Cross-Busy detection
Guard Tone or DC Control detection (LOTL) optional
Recorder Outputs 1 per channel (TX/RX audio summation), plus 1 output per console (various
combinations of select, unselect and microphone audio)
0 dBm level, 600Ω, single-ended outputs
Capacity 12 radio channels plus 1 or 2 phone lines with an optional phone patch card
Operating Temp. +5° to +50° Celsius
Voltage +13.5 V
DC
(+11.5 V
DC
minimum — +16.0 V
DC
maximum)
Current 2.5 amperes maximum
Voltage +13.5 V
DC
± 0.5 volts
Current 7 amperes
AC Input 95 to 250 V
AC
, 47 to 63 Hz
Approval CE
Model 4010
Size height = 9″ x width = 18″ x depth = 14″ inches
Weight 15 pounds
Model 4010R
Size height = 10.5″ x width = 19″ x depth = 10.5″ inches
Weight 15 pounds
Model 4115B
Size height = 5.25″ x width = 19″ x depth = 2.25″ inches
Weight 4 pounds
