Console Installation
38 025-9227S
Outputs
The Console has eight outputs, which can be programmed through CPSW. Outputs 1-4 are
open collector drivers that can drive 0 to 25 V
DC
, 200 mA. Although the open collector
outputs can each source 200 mA, only one collector output can be active at a time. If more
than one is to be activated, the load should be no more than 100 mA.
Outputs 5-8 are relay outputs which have the common (C) and normally open (NO)
contacts brought out to connector P7. These contacts are capable of 1 Amp and 50 V
non-inductive load. Wiring access is through the rear of the unit. The mating connector is
provided with the unit. The connector pinout is listed in Table 9.
Table 9: P7 Outputs
Output 1 has a special function that can be used to generate an off-hook signal for the
TRHI (see Telephone/Radio Headset Interface on page 53).
Signal P7 Pin # Signal P7 Pin #
OUTPUT 1 1 OUTPUT 6 - NO 8
OUTPUT 2 2 OUTPUT 7 - C 9
OUTPUT 3 3 OUTPUT 7 - NO 10
OUTPUT 4 4 OUTPUT 8 - C 11
OUTPUT 5 - C 5 OUTPUT 8 - NO 12
OUTPUT 5 - NO 6 GROUND 13
OUTPUT 6 - C 7 GROUND 14
