Overview
17
Console Installation
Overview
The Model 4010 Communication Console is a self-contained unit, which makes for an
easy installation. Accessories may be added to the console including headset jack box,
desk microphone, handset (desktop unit only), gooseneck microphone, footswitch, and
telephone/radio headset interface. The handset and gooseneck microphone options are
installed at the factory if ordered with the console. They are also an easily added option if
ordered later. Instructions for installing options are included in the following chapter,
Option Installation on page 47.
Major sections in this chapter:
• Important Notes on page 18
• Physical Installation on page 18
• Power on page 19
• System Grounding on page 20
• Slot Mapping on page 21
• Configuring Dispatch Consoles on page 24
• Configuring Dual Channel Cards on page 26
• Wiring to the Channels on page 31
• Split 50 66m Type Punch-Down Block on page 35
• Inputs and Outputs on page 37
• Outputs on page 38
• Auxiliary Audio on page 39
• Labeling on page 39
• Model 4115B Connections on page 40
• Preliminary System Check on page 41
• Level Adjustments on page 42
