Model 4010 T2-2R Base Station Installation
Model 4010 T2-2R Base Station Installation
There are two methods of installing a T2-2R base station to a Model 4010 Console.
Method 1
This method allocates one system channel to the T2-2R base station.
Advantage: Uses only one system channel instead of two. The installation is simple.
Disadvantage: Both receivers are summed together giving only one mute button, one
channel volume control, and one call indicator.
Figure 11: T2-2R installation method 1
Programming: Program the channel as a T2-2R channel. In addition to a channel select
button, include a F1/F2 button (sent at Xmit) for transmit frequency selection, and
optionally an R2 On/Off button for second receiver muting at the base station. If Instant
Select is desired, use an F1-select and an F2-select button instead of the conventional
select button.
Method 2
This method allocates two system channels to the T2-2R base station.
Advantage: Each receiver is given its own channel and thus individual mutes, channel
volumes and call indicators.
Disadvantage: Requires two system channels and more complex installation.
Transmitter
First
Frequency
Receiver
Second
Frequency
Receiver
2-Wire TX/RX
4-Wire RX
Base Station
Dual Channel Card
