DC and Tone Remote Function Definitions
Table 32: DC Remote Function Definition
Table 33: Tone Remote Function Definition
Current
T1R1
STD
T1R1
PAGING
T2R2 T4R4
0.0 mA RX RX RX RX
+2.5 mA————
+5.0 mA F1 — F1 F1
+7.5 mA————
+10.0 mA — — — —
+12.5 mA RPTR ON F1 W PL F2 F2
+15.0 mA — — — —
+15.5 mA — — — —
-2.5 mAPL MONPL MONPL MONPL MON
-5.0 mA RPTR OFF — R2 OFF F3
-7.5 mA————
-10.0 mA — — — —
-12.5 mA — F1 W/O PL — F4
-15.0 mA — — — —
-15.5 mA — — — —
Tone Freq T1R1 T2R2 T4R4 T8R8
650Hz — — — —
750Hz — — — —
850Hz — — — F8
950Hz — — — F7
1050Hz PL4/WC 2 OFF PL4/WC 2 OFF WC 2 OFF F6
1150Hz PL3/WC 2 ON PL3/WC 2 ON WC 2 ON F5
1250Hz PL2/WC 1 OFF PL2/WC 1 OFF F4 F4
1350Hz PL1/WC 1 ON PL1/WC 1 ON F3 F3
1450Hz RPTR ON RPTR ON RPTR ON RPTR ON
1550Hz RPTR OFF RPTR OFF RPTR OFF RPTR OFF
1650Hz R2 ON R2 ON R2 ON R2 ON
1750Hz R2 OFF R2 OFF R2 OFF R2 OFF
1850Hz F1 W/O PL F2 F2 F2
1950Hz F1 F1 F1 F1
2050Hz PL MON PL MON PL MON PL MON
