Option Installation
60 025-9227S
Table 19: Signal vs. Pin Assignment — Lower Half
Signal Pin Pin Signal
open 38 13 Input 1
Analog GND 39 14 Input 2
Ground 40 15 Input 3
open 41 16 Input 4
RLY1B 4217RLY1A
RLY2B 4318RLY2A
RLY3B 4419RLY3A
Ground 45 20 Input 5
open 46 21 Input 6
RLY4B 4722RLY4A
RLY5B 4823RLY5A
RLY6B 4924RLY6A
