87
CPSW Menu Structure
6. If applicable, select the DC Control Current or Tone Frequency used for channel
monitor. See
DC and Tone Remote Function Definitions on page 110 for a description
of the control currents and tone frequencies.
The options for channel monitor depend upon the channel type and some channel
types may not support a monitor function at all.
7. If applicable, enter a value from 0.0 to 10.0 seconds for Keyup Delay to set the
time delay between when the channel has finished keying up the transmitter and
the start of the first page in a stack.
8. If applicable, enter a value from 0.0 to 10.0 seconds for Inter-Stack Delay to set
the time delay between pages in a stack. This delay will only occur for manually
entered page stacks (i.e., for two or more pages entered via Paging/DTMF keypad).
Because each page can be sent out over different channels, Instant-Call (single
button) paging stacks always use the Keyup Delay between pages even if the next
page uses the same channel as the previous page.
9. If applicable, select the DC Control Current or Tone Frequency used for paging
function. See Appendix B: CPSW Reference Material on page 109
for a description
of the control currents and tone frequencies.
The options for channel monitor depend upon the channel type and some channel
types may not support a monitor function at all.
10. If applicable, enable or disable De Emphasis by marking or clearing its checkbox.
De Emphasis may need to be enabled if the radios transmitting via the console are
using Pre Emphasis. If you are uncertain, leave De Emphasis disabled.
11. If you have additional channels to configure, click Next or Previous and repeat
this procedure.
12. If you are finished configuring channels for now, click Done.
♦ To delete or clear a channel’s configuration
1. There are two ways to delete a channel’s configuration:
a. If you want to delete a channel’s configuration but retain the channel name,
change the Channel Type to No Control Type Selected.
b. If you want to delete a channel’s configuration including the channel name,
click Delete or change the Channel Type to Undefined.
T4R4
Without PL
Four-frequency tone controlled remote radio without PL. Refer to DC and Tone
Remote Function Definitions on page 110 for a list of the frequencies generated.
T8R8 This is an eight-frequency tone controlled remote radio. Refer to DC and Tone
Remote Function Definitions on page 110 for a list of the tones required to
control this type of radio.
Control
Protocol
Description
