Zimmer PhySys - Electrotherapy Controls

Operation instructions
9.1 Electrotherapy
9
Page 21
(1) Intensity
Displays the intensity adjusted.
(2) Parameters
Shows the parameters of the current therapy program.
The following parameters are displayed:
• Impulse and impulse pause time and thus the frequency
• Polarity, CC/CV, galvanic proportion
Activation of the “Parameters” button opens the “Current form parameters” window.
Here the parameters can be modified in a user-defined way.
The impulse parameters to be changed are selected using arrow buttons.
The arrow buttons can be used to modify the values up or down within the limits
specified in the current form definition.
The polarity is changed and the CC/CV and galvanic proportion are switched by
activating the corresponding button.
(3) Vacuum
Indicates in the therapy screen that the vacuum unit is connected. Activation of the
“Vacuum” button opens the “Vacuum” settings and start screen.
(4) Surge
When activated, this shows the surge parameters of the current therapy program.
The following parameters are displayed:
Rise time, hold time, pause time.
If no surge is activated, the surge window is shown in minimised form.
Activation of the “Surge” button opens the “Surge parameters” window. Here a surge
can be activated or the parameters can be changed in a user-defined manner.
Note:
If no surge is intended for a program as a default, the window is completely hidden.
Note:
When parameters are changed, activating the “OK” button applies the changes.
Activating the “Cancel” button interrupts the process.
(5) Effects
Gives an overview of the effects associated with the present current form.
Note:
If the waveform parameters (pulse time or pulse pause) are changed, the mode of
action of the current form also changes. For this reason, the window is no longer visible
after a change.
(6) Therapy time
Displays the therapy time.
(7) Channel
Switch to channel mode.
(8) Time min/s
Activating the button increases the therapy time.
(9) Stop
Activating the button ends the therapy before the therapy time has elapsed.
(10) Pause
Activation of the button stops the therapy time and interrupts the therapy.
(11) Start
Activation of the button in pause mode continues the therapy.
Activation of the button after the therapy time has elapsed resets the therapy time to
the preset value.
(12) Time min/s
Activating the button decreases the therapy time.
