Operation instructions
9.6 Information on the operation of VacoP
9
Page 29
The VacoP integrated in the column contains a water separator which collects moisture
emitted from the sponges and thus protects the vacuum unit from calcification.
Note:
Before you empty the water separator, remove any Vaco electrode from the tube.
Emptying the water
separator
Empty the water separator by opening the discharge tap.
The discharge tap is located on the underside of the VacoP.
Close the discharge tap afterwards.
We recommend emptying the water separator daily.
Note:
After closing, ensure that the discharge tap is at an angle of 90° to the flow direction (see Fig.).
VacoP and “DuoStim
separate” mode
In the “DuoStim separate” mode, a dual circuit vacuum application is not possible.
In the “DuoStim separate” mode, only channel I is active for vacuum application. Channel II
cannot be operated with vacuum application.
