Zimmer PhySys - Page 3

Illustrations
Back of the device
Fig. 3
Ports
6
Port for ultrasound transducer 0.8/2.4 MHz
7 Port for patient cable channel II
8 Connection for power cable
9 Port for patient cable channel I
10 Port for ultrasound transducer 0.8/2.4 MHz
11 Port without function
12 Identification plate
6
7
8
9
10
11
12
