Specifications
Maximum number of simultaneous effects 9 effects
User patches 240
Sampling frequency 44.1 kHz
A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Frequency characteristics 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (10kΩ load)
Display 4.3″ TFT color LCD (480×272)
Inputs INPUT Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 500 kΩ
RETURN Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 1 MΩ
AUX IN Stereo mini jack
Rated input level: −10 dBu
Input impedance (line): 10 kΩ
Outputs OUTPUT R Standard mono phone jack
Maximum output level: +11.4 dBu (when output impedance 10 kΩ or higher)
OUTPUT L/MONO
[PHONES]
Standard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 kΩ or higher)
Headphones 24 mW + 24 mW (at 32Ω load)
SEND Standard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 kΩ or higher)
Input S/N 123 dB
Noise floor (residual noise)
L/R −99.3 dBu
SEND −99.0 dBu
Control input FP02M input
Power AC adapter (9V DC 500mA, center negative) (ZOOM AD-16)
USB Port: USB 2.0 Micro-B/Supported cable type: Micro-B
Guitar Lab: USB 1.1 Full Speed
Audio interface: USB 2.0 Full Speed, 44.1kHz/32-bit, 2 in, 2 out
• Use a USB cable that supports data transfer. USB bus power is not supported.
SD card Standards Cards that support SD/SDHC/SDXC specifications (Class 10 or higher)
LOOPER 44.1kHz/16-bit stereo WAV
IR 44.1–192kHz, 16/24/32-bit WAV
REMOTE ZOOM BTA-1 or other dedicated wireless adapter
External dimensions 228 mm (D) × 418 mm (W) × 65 mm (H)
Weight 1.94 kg
Note: 0 dBu = 0.775 V
